Electric Wheelchair (Large Wheel) Model Model DW WD301

The DW-WD301 is an electric wheelchair designed for both indoor and outdoor use, offering users flexibility and convenience. Below are its key specifications:

Dimensions and Weight:

• Overall Size: Approximately 1090 mm (length) x 685 mm (width) x 930 mm (height)
• Folded Size: Approximately 805 mm (length) x 500 mm (width) x 730 mm (height)
• Net Weight (Without Battery): Approximately 34 kg
• Gross Weight: Approximately 46 kg
• Loading Capacity: Up to 100 kg

Motors and Performance:

• Motors: Two DC 250W motors
• Brake System: Electromagnetic brakes for enhanced safety

Battery and Range:

• Battery: 12V 20Ah lead-acid battery
• Driving Range: Approximately 15-20 km per charge
• Charging Time: Approximately 3.5 hours

Wheels:

• Front Wheels: 8-inch solid PU tires
• Rear Wheels: 12-inch pneumatic tires

Frame and Design:

• Frame Material: Steel
• Foldability: Foldable design for easy storage and transportation
• Armrests and Footrests: Flip-up armrests; adjustable and detachable footrests

Additional Features:

• Controller: Joystick can be mounted on either the left or right armrest
• Driving Modes: Option to operate in both manual and electric modes
• Battery Box: Removable for convenient recharging
• Turning Radius: Approximately 600 mm
• Climbing Ability: Capable of navigating slopes up to 10°

These specifications make the DW-WD301 a reliable choice for users seeking a balance between performance and portability in an electric wheelchair. citeturn0search3
